Professional paper tube packaging equipment manufacturer since 2005

Composite paper tube labeling machine | Cardboard tube labeling machine | Paper tube labeling machine

Composite paper tube labeling machine | Cardboard tube labeling machine | Paper tube labeling machine

Composite paper tube labeling machine | Cardboard tube labeling machine  |  Paper tube labeling machine

Composite paper tube labeling machine | Cardboard tube labeling machine | Paper tube labeling machine

Description of the machine:

● The standard library can hold 1500 labels at a time, eliminating the need to repeatedly adjust the position accuracy of the labels in the standard library,   saving a lot of startup time.

●Unique bidding technology ensures the continuous and uninterrupted work  of the machine. Don't worry about card labels, double sheets and other issues. Effectively reduce the scrap rate.

●The stepping motor drives the gripper mechanism, it will not label without tubes; do not feed tube without label. Can be equipped with auxiliary input  double sheet shutdown detection system.

●Using the printing machine gripper positioning and clamping labeltechnology, the label is released at the last moment before labeling, which well guarantees the labeling accuracy.


CONTACT US SEND INQUIRY NOW

Technical Parameters:

● Inlet mode: automatic (or manual)

● Out of tube mode:automatic

● Cleaning method: no need to clean

Item

Data

ModelSM600-HL Hot Glue Paper Tube Labeling Machine

Applicable tank diameter

Φ30-Φ130MM(30-40mmneed to switch to manual)

Applicable label height

130-600mm

Applicable label thickness

80-157g

Voltage

Can be Selected

Speed

22-27 pcs/min.

Working Air Pressure

0.4Mpa

Rated power

2.1KW

Operator

1 Person

Dimenson

L2400* W1200 * H1400mm

Weight

680kgs



IF YOU HAVE MORE QUESTIONS,WRITE TO US

Just tell us your requirements, we can do more than you can imagine.
