Paper tube hot-melt adhesive labeling machine

Paper tube hot-melt adhesive labeling machine

Paper tube hot-melt adhesive labeling machine

Paper tube hot-melt adhesive labeling machine

Technical Parameter:

● Inlet mode: automatic (or manual)

● Out of tube mode: automatic

● Cleaning method: no need to clean

● Applicable tank diameter: Φ30-Φ130MM

● Applicable label height: 130-600mm

●Applicable label thickness: 75-157g

● Applicable paper tube wall thickness: 0.8-15mm

● Air pressure: 0.4Mpa

● Rated power: 2.1kw


2024/07/18

CONTACT US SEND INQUIRY NOW

Equipment Introduction:

● The standard library can hold 2000 labels at a time, eliminating the need to repeatedly adjust the position accuracy of the labels in the standard library, saving a lot of startup time.

● The marking accuracy can reach the alignment level by using the printing machine Diao tooth technology. The edge alignment accuracy can be within 0.3mm.

● The stepping motor drives the gripper mechanism, it will not label without tubes; do not feed tube without label. Can be equipped with auxiliary input double-sheet shutdown detection system.

● Using the printing machine gripper positioning and clamping label technology, the label is released at the last moment before labeling, which well guarantees the labeling accuracy.
